SOA Application Missing in Jdeveloper 12C

Sep 19, 2018

Share this post


After JDeveloper 12C installation,  SOA tire Application is not coming as by default project even after multiple extensions updates as like below screenshot.


Reinstall the JDeveloper with following below steps:

    • Deinstall JDeveloper by launching the script- Path – “C:\Oracle\Middleware\product\Oracle_Home\oui\bin\deinstall.cmd”.
    • Remove leftover directories- “C:\Oracle\Middleware” “C:\Users\XXXXX\AppData\Roaming\JDeveloper\system12.” “C:\Users\XXXXX\AppData\Roaming\JDeveloper\”
    • Create a symbolic link “C:\Program_Files” to the directory “C:\Program Files”. You can also install JDK to a different path which doesn’t contain any spaces.
    • Set JAVA_HOME environment variable to “C:\Program_Files\Java\jdk1.7.0_80”.
    • Set PATH=C:\Program_Files\Java\jdk1.7.0_80\bin;%PATH%
    • Launch the installer from admin command prompt: java -jar fmw_12.
    • After installing the JDeveloper You can check on Help à About à version à You can find SOA composite editor or You can check on Application gallery.
